Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Florescence
  • Model Number: D3.3m*L4.5m
  • Material:: Natural rubber:RSS3(imported from Thailand)
  • Standard color: Black
  • Model size: D3.3m * L4.5m
  • Fender weight: 3170 kg
  • Available diameter: From 0.5m to 3.3m
  • Effective length:: From 1.0m to 6.5m
  • Part: Chain, tyres net, pressure gauge, spanner, valve core
  • Standard: ISO 17357: 2002
  • Warranty period: 12 months
  • Application: For ship berthing, ship to ship operation, docks and ports, etc.

Packaging & Delivery

Packaging Details: Without packages or according to customers' demands
Delivery Detail: Within 20 days when confirm your payment



 FLOATING PNEUMATIC SHIP RUBBER FENDER

comply with ISO 17357

Fender Description

1. Florescence floating pneumatic ship rubber fender structure

Floating marine ship rubber fender is made of synthetic-cord-reinforced rubber sheet with compressed air inside to enable it to float on the water and work as a shock absorber between two ships, or between ships and berthing structures when they come alongside each other on the water.



The fender body is constructed of an inner rubber layer, reinforced cord layers and an outer rubber layer. All of these layers are vulcanized together.



The outer skin rubber compound is designed and manufactured to be able to withstand both strenuous use including abrasion during adverse weather conditions whilst protecting the cord layers and inner rubber.



The synthetic tyre cord layers are arranged and designed to distribute load and stress evenly, which maintains the internal air pressure of the fender.



The inner rubber compound is designed to be completely airtight, utilising a compound equivalent tothat an inner tube of a car tyre.



2. Classification of pneumatic ship rubber fender:



Fender types:

1.Net-type fenders: fenders which are covered by a tire chain net, each end shall be linked together with one to two ring(s).

2.Sling-type fender: fenders which are designed to be used without a protection net.



Initial internal pressure:

1.Pneumatic fender 50 (initial internal pressure 50 KPa)

2.Pneumatic fender 80 (initial internal pressure 80 KPa)

Fender Application

3. Pneumatic marine ship rubber fender application

Floating pneumatic marine ship rubber fender could be used as a protective medium for ship-to-ship operation(STS), ship-to-quay(STQ) and ship-to-berthing(STB). And suit for various vessels, like:



1. TankersGas Carriers and Bulk Cargo Ships;

2. Fast ferries and aluminum hulled vessels;

3. Temporary of permanent installations;

4. Rapid response and emergency fendering;

5. As stand-off fenders to realign ships with shore facilities.

Fender Installation

4. How to install floating marine ship rubber fender?



Fix the lifting rope to the swivels on the fender’s chain lugs

Lift the fender well clear of the ground and any projections.

Lowering the fender into position

Connect the chains to the fender’s chain lugs.

Lower the fender to the water.

Fix the chains to the anchors on the quay wall.

Pneumatic rubber fender install at Docks





Pneumatic rubber fender install at Ships



Fender Inflation

5. How to inflate floating marine rubber fender?



Fender Specification

6. Technical Parameters of marine ship rubber fender

Specification
 D*L(m)

Initial pneumatic pressure
50KPa

Initial pneumatic pressure
80KPa

Applicable
ships
tonnage
(T)

Body
Weight
(Kg)

  R
 (KN)

GEA
 (KJ)

Body
Weight
(Kg)


(KN)

GEA
(KJ)

0.5*1.0

25

64

6

25

83

8

50

0.6*1.0

32

74

8

32

96

11

50

1.0*1.5

80

182

32

80

235

44

100

1.0*2.0

100

257

45

125

335

63

200

1.2*2.0

120

297

63

165

386

86

300-500

1.35*2.5

165

427

102

226

554

140

300-500

1.5*3.0

315

597

153

370

751

211

1000

1.7*3.0

405

639

191

436

830

263

1000

2.0*3.5

590

875

308

632

1138

424

3000

2.5*4.0

1050

1381

663

1110

1815

925

10000

2.5*5.5

1333

2019

943

1410

2653

1317

10000

3.0*5.0

1880

2104

1210

2155

2709

1571

10000above

3.0*6.0

2160

2583

1485

2470

3292

1888

10000above

3.3*4.5

2020

1884

1175

2300

2476

1640

10000above

3.3*6.5

2700

3015

1814

3080

3961

2532

10000above



Fender Pictures

 7. Florescence vatious size marine ship rubber fender pictures
